NOTE: The information below is provided for your convenience only; the accuracy of the specifications cannot be guaranteed. However, if necessary, please check with us before purchasing. Data provided by 1 World Sync.
General
Maximum data transfer rate
3550 Mbit/s
Ethernet LAN data rates
1000,2500 Mbit/s
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11e,IEEE 802.11g,IEEE 802.11n,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1x,IEEE 802.3af,IEEE 802.3at
Security algorithms
WEP,WPA,WPA-AES,WPA-PSK,WPA-TKIP,WPA2,WPA2-AES,WPA2-PSK,WPA2-TKIP,WPA3
Supported network protocols
IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
Placement
Ceiling, Wall
Product colour
White
Cable lock slot
Y
Cable lock slot type
Kensington
Antenna type
Internal
Antenna gain level (max)
4 dBi
Grandstream Networks GWN7664. Maximum data transfer rate: 3550 Mbit/s, Ethernet LAN data rates: 1000,2500 Mbit/s, Networking standards: IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11e,IEEE 802.11g,IEEE 802.11n,IEEE.... Security algorithms: WEP,WPA,WPA-AES,WPA-PSK,WPA-TKIP,WPA2,WPA2-AES,WPA2-PSK,WPA2-TKIP,WPA3. Supported network protocols: IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM. Placement: Ceiling, Wall, Product colour: White, Cable lock slot type: Kensington. Antenna type: Internal, Antenna gain level (max): 4 dBi
| Estimate Gross Weight | 1.09 |
|---|
The GWN7664 offers dual-band 4x4:4 MU-MIMO with DL/UL OFDMA technology and a sophisticated internal antenna design for stronger anti-interference, more stable connection, maximum network throughput and expanded Wi-Fi coverage range, ideal for business-grade wireless network deployments with medium-to-high user density.
The GWN7664 is a powerful, enterprise-grade 802.11ax Wi-Fi 6 access point, ideal for small-to-medium sized businesses, multiple floor buildings, residential settings and commercial locations. It offers dual-band 4x4:4 MUMIMO with DL/UL OFDMA technology and a sophisticated internal antenna design for stronger anti-interference, more stable connection, maximum network throughput and expanded Wi-Fi cover age range. The GWN7664 is supported by GWN.Cloud and GWN Manager, GrandstreamΓÇÖs cloud and on-premise Wi-Fi management platform that and makes managing your network or several networks across multiple locations easier than ever before. It also uses a controller-less network management architecture in which the controller is embedded within the productΓÇÖs web user interface for easy administration of locally deployed Wi-Fi Aps. The GWN7664 is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with GrandstreamΓÇÖs Wi-Fi capable IP phones. With support for advanced QoS, low latency real-time applications, mesh networks, captive portals, 512 concurrent clients and dual Gigabit network ports with PoE/PoE+, the GWN7664 is an ideal Wi-Fi access point for business-grade wireless network deployments with medium-to-high user density.
- 3.55Gbps aggregate wireless throughput, 3.5Gbps aggregate wired throughput
- Dual-band 4x4:4 MU-MIMO with DL/UL OFDMA technology
- Up to 175-meter coverage range
- Supports 512 concurrent Wi-Fi client devices
- Includes 1x 1G Port and 1x 2.5G Port
- Advanced QoS to ensure real-time performance of low-latency applications
- Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
- Self power adaptation upon auto detection of PoE or PoE+
- Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management
